【图象几何】基于matlab GUI图象空间变换（仿射变换）【含Matlab源码 841期】-英雄云拓展知识分享

一、获得代码方式

获得代码方式1：
经过定阅紫极神光博客付费专栏，凭支付凭证，私信博主，可取得此代码。

获得代码方式2：
完全代码已上传我的资源：【GUI841期】

备注：
定阅紫极神光博客付费专栏，可免费取得1份代码（行之有效的期为定阅日起，3天内行之有效的）；

2、空间变换（仿射变换）简介

1 概念
在transformation）分成两类情况，有仿射变换（Affine Transformation）及投影变换（Perspective Transformation）。
仿射变换是从一个2维坐标变换到另外一个2维坐标，它是一种线性变换，保持了而投影变换则是指利用投影光束映照对数学上的表示而言，这二者都是一样的，始终存在着一个变换矩阵使得原举个例子

如上经过一定的变换关系，使得f变换到g。如果我们知道对应角点的坐标，则可以经过以下的式子进行推算。

3、部份源代码

function varargout = affine_trans(varargin)
% AFFINE_TRANS M-file for affine_trans.fig
%      AFFINE_TRANS, by itself, creates a new AFFINE_TRANS or raises the existing
%      singleton*.
%
%      H = AFFINE_TRANS returns the handle to a new AFFINE_TRANS or the handle to
%      the existing singleton*.
%
%      AFFINE_TRANS('CALLBACK',hObject,eventData,handles,...) calls the local
%      function named CALLBACK in AFFINE_TRANS.M with the given input arguments.
%
%      AFFINE_TRANS('Property','Value',...) creates a new AFFINE_TRANS or raises the
%      existing singleton*.  Starting from the left, property value pairs are
%      applied to the GUI before affine_trans_OpeningFunction gets called.  An
%      unrecognized property name or invalid value makes property application
%      stop.  All inputs are passed to affine_trans_OpeningFcn via varargin.
%
%      *See GUI Options on GUIDE's Tools menu.  Choose "GUI allows only one
%      instance to run (singleton)".
%
% See also: GUIDE, GUIDATA, GUIHANDLES
% Edit the above text to modify the response to help affine_trans
% Last Modified by GUIDE v2.5 21-May⑵009 16:53:05
% Begin initialization code - DO NOT EDIT
gui_Singleton = 1;
gui_State = struct('gui_Name',       mfilename, ...
'gui_Singleton',  gui_Singleton, ...
'gui_OpeningFcn', @affine_trans_OpeningFcn, ...
'gui_OutputFcn',  @affine_trans_OutputFcn, ...
'gui_LayoutFcn',  [] , ...
'gui_Callback',   []);
if nargin & isstr(varargin{1})
gui_State.gui_Callback = str2func(varargin{1});
end
if nargout
[varargout{1:nargout}] = gui_mainfcn(gui_State, varargin{:});
else
gui_mainfcn(gui_State, varargin{:});
end
% End initialization code - DO NOT EDIT
% --- Executes just before affine_trans is made visible.
function affine_trans_OpeningFcn(hObject, eventdata, handles, varargin)
% This function has no output args, see OutputFcn.
% hObject    handle to figure
% eventdata  reserved - to be defined in a future version of MATLAB
% handles    structure with handles and user data (see GUIDATA)
% varargin   command line arguments to affine_trans (see VARARGIN)
f = checkerboard(50);
axes(handles.axes1);
imshow(f);
s = 0.8;
theta = pi/6;
T = [s*cos(theta) s*sin(theta) 0
-s*sin(theta) s*cos(theta) 0
0          0          1];
tform = maketform('affine',T);
g = imtransform(f,tform,'nearest');
axes(handles.axes2);
imshow(g);
set(handles.theta_edit,'string',30);
% Choose default command line output for affine_trans
handles.output = hObject;
% Update handles structure
guidata(hObject, handles);
% UIWAIT makes affine_trans wait for user response (see UIRESUME)
% uiwait(handles.figure1);
% --- Outputs from this function are returned to the command line.
function varargout = affine_trans_OutputFcn(hObject, eventdata, handles)
% varargout  cell array for returning output args (see VARARGOUT);
% hObject    handle to figure
% eventdata  reserved - to be defined in a future version of MATLAB
% handles    structure with handles and user data (see GUIDATA)
% Get default command line output from handles structure
varargout{1} = handles.output;
% --- Executes during object creation, after setting all properties.
function theta_edit_CreateFcn(hObject, eventdata, handles)
% hObject    handle to θ_edit (see GCBO)
% eventdata  reserved - to be defined in a future version of MATLAB
% handles    empty - handles not created until after all CreateFcns called
% Hint: edit controls usually have a white backgROUND on Windows.
%       See ISPC and COMPUTER.
if ispc
set(hObject,'BackgroundColor','white');
else
set(hObject,'BackgroundColor',get(0,'defaultUicontrolBackgroundColor'));
end
function theta_edit_Callback(hObject, eventdata, handles)
% hObject    handle to θ_edit (see GCBO)
% eventdata  reserved - to be defined in a future version of MATLAB
% handles    structure with handles and user data (see GUIDATA)
% Hints: get(hObject,'String') returns contents of θ_edit as text
%        str2double(get(hObject,'String')) returns contents of θ_edit as a double
% --- Executes during object creation, after setting all properties.
function intERPolate_pop_menu_CreateFcn(hObject, eventdata, handles)
% hObject    handle to interpolate_pop_menu (see GCBO)
% eventdata  reserved - to be defined in a future version of MATLAB
% handles    empty - handles not created until after all CreateFcns called
% Hint: popupmenu controls usually have a white background on Windows.
%       See ISPC and COMPUTER.
if ispc
set(hObject,'BackgroundColor','white');
else
set(hObject,'BackgroundColor',get(0,'defaultUicontrolBackgroundColor'));
end
% --- Executes on selection change in interpolate_pop_menu.
function interpolate_pop_menu_Callback(hObject, eventdata, handles)
% hObject    handle to interpolate_pop_menu (see GCBO)
% eventdata  reserved - to be defined in a future version of MATLAB
% handles    structure with handles and user data (see GUIDATA)
% Hints: contents = get(hObject,'String') returns interpolate_pop_menu contents as cell array
%        contents{get(hObject,'Value')} returns selected item from interpolate_pop_menu
